3,000 – 8,000 LB. CAPACITY INTERNAL COMBUSTION CUSHION TIRE FORKLIFTS FGC15N-FGC40CN LP cushion tire model series delivers increased uptime, maneuverability and performance. Contact a Sales Rep […]
3,000 – 8,000 LB. CAPACITY INTERNAL COMBUSTION CUSHION TIRE FORKLIFTS
FGC15N-FGC40CN LP cushion tire model series delivers increased uptime, maneuverability and performance.
UPTIME
Self-Diagnostics
Standard warnings and icons on the display provide immediate truck status to help streamline troubleshooting.
Effective Cooling System
An electronic engine protection and warning system monitors radiator fluid and transmission oil temperatures while the bottom bypass air flow design allows air flow during travel, helping prolong engine life.
Extended Preventative Maintenance Schedule
500-hour service intervals mean that labor, parts and downtime required for preventative maintenance are kept to minimal levels.
MANEUVERABILITY
Compact Chassis
The compact chassis allows the operator to get in, out and around tight spaces efficiently.
Fully Hydrostatic Power Steering
The steering system enables maneuverability with less components and less effort, helping to improve productivity.
OPERATOR COMFORT
Reduced Vibration
The engine of the truck rests on rubber cushion dampeners designed to absorb vibration during operation.
Ergonomic Operator Compartment
The spacious cabin design features ergonomic leg room and pedal position to rest feet in a comfortable position, alleviating unnecessary stress in the ankles.
Full Suspension Vinyl Seat
The seat, suspension and lumbar support can be adjusted to a wide range of operator sizes comfortable throughout the shift.
POWER
GK25 internal combustion engine
This powerful engine provides high levels of horsepower, while maintaining compliance with all CARB and EPA emissions regulations.
Electronic fuel injection system
Consisting of three control modules, the combustion process provides high levels of torque at lower RPM levels, saving in fuel consumption.
Fuel Saver Mode
This optional feature is easily activated by a toggle switch on the dashboard, saving on fuel costs without sacrificing the top travel speeds of the truck.
AWARENESS
Cushioned Stability Control
The rubber damper mounted between the steer axle and frame can improve increased lateral stability, enhancing operator confidence and overall driving experience.
Standard Lights Package
With LED standard work lights mounted on the front of the overhead guard, operators have increased visibility to the area in front of the truck and through the mast to the fork tips, to operate with precision and efficiency.
Functional Steering Column
The steering column is combined with an open concept steering wheel that provides full visibility to the display. The operator can adjust the tilt column and use the memory feature to reposition the column in the prior tilt position in case the operator leaves the compartment.
| Model | Basic Capacity (lbs) | Voltage (or Fuel Type) | Length To Fork Face | Length to Fork Face | Chassis Width (in) | Chassis Height (in)1 | Gross Weight (lbs)1 |
|---|---|---|---|---|---|---|---|
|
Model
FDC15N |
Basic Capacity (lbs)
3,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
81.9 |
Chassis Width (in)
38.2 |
Chassis Height (in)1
82.9 |
Gross Weight (lbs)1
7,720 |
|
Model
FGC18N |
Basic Capacity (lbs)
3,500 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
81.9 |
Chassis Width (in)
45.9 |
Chassis Height (in)1
38.2 |
Gross Weight (lbs)1
6,420 |
|
Model
FGC20CN |
Basic Capacity (lbs)
4,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
84.4 |
Chassis Width (in)
38.2 |
Chassis Height (in)1
82.9 |
Gross Weight (lbs)1
9,240 |
|
Model
FGC20N |
Basic Capacity (lbs)
4,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
89 |
Chassis Width (in)
36.2 |
Chassis Height (in)1
83.1 |
Gross Weight (lbs)1
9,730 |
|
Model
GC25N |
Basic Capacity (lbs)
5,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
91.3 |
Chassis Width (in)
36.2 |
Chassis Height (in)1
83.1 |
Gross Weight (lbs)1
11,375 |
|
Model
GC28N |
Basic Capacity (lbs)
5,500 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
93.9 |
Chassis Width (in)
43.1 |
Chassis Height (in)1
82.7 |
Gross Weight (lbs)1
12,355 |
|
Model
GC28N |
Basic Capacity (lbs)
6,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
95.3 |
Chassis Width (in)
43.1 |
Chassis Height (in)1
82.7 |
Gross Weight (lbs)1
13,380 |
|
Model
GC30EN |
Basic Capacity (lbs)
6,000 |
Voltage (or Fuel Type)
130 |
Length To Fork Face
12 |
Length to Fork Face
96.5 |
Chassis Width (in)
43.9 |
Chassis Height (in)1
83.1 |
Gross Weight (lbs)1
13,715 |
|
Model
GC33N |
Basic Capacity (lbs)
6,500 |
Voltage (or Fuel Type)
122 |
Length To Fork Face
12 |
Length to Fork Face
96.3 |
Chassis Width (in)
43.9 |
Chassis Height (in)1
82.7 |
Gross Weight (lbs)1
14,255 |
|
Model
GC35CN |
Basic Capacity (lbs)
7,000 |
Voltage (or Fuel Type)
171 |
Length To Fork Face
12 |
Length to Fork Face
98.2 |
Chassis Width (in)
45.9 |
Chassis Height (in)1
83.1 |
Gross Weight (lbs)1
15,365 |
|
Model
GC40CN |
Basic Capacity (lbs)
8,000 |
Voltage (or Fuel Type)
171 |
Length To Fork Face
12 |
Length to Fork Face
98.2 |
Chassis Width (in)
45.9 |
Chassis Height (in)1
83.1 |
Gross Weight (lbs)1
16,910 |
1 Where applicable, does not reflect optional mast collapsed height or additional weight.
2 Various lift heights available to match your exact needs. Where applicable, value shown is maximum fork height available as an optional mast.
