2,500 - 4,000 LB. CAPACITY ELECTRIC PNEUMATIC TIRE LIFT TRUCKS

The 2ET2500-2ET4000 three-wheel series electric pneumatic tire forklifts combine the latest in operator ergonomics, advanced AC control systems and customized performance.

  • Features
  • Specifications
  • Downloads

Productivity

Powerful 3-Phase AC Technology

Optimized productivity makes this an incredibly energy-efficient electric forklift, allowing two shifts with one battery charge in many applications.

Display Panel

The high definition and high contrast full color display includes information on service icons, directional indicators and performance modes.

Selective Performance Modes

Five-level pre-programmed performance mode selector lets you adapt to various applications.

Durability

Sealed Components

Electric motors protected to IP54, electro-magnetic brakes and short cables help protect components from dust and moisture, helping to minimize forklift downtime and extend service intervals.

Serviceability

Performance Customization

Exclusive and comprehensive servicing software allows the factory-trained technician the ability to perfectly match performance parameters to your application.

Awareness

Curve Control

Curve Control automatically reduces speed while turning corners, helping to ensure control over loads.

Visibility

Optimum visibility in all directions due to mast, overhead guard and counterweight design.

Operator Comfort

Electric Power Steering

Fully AC power steering provides significantly lower steering effort than a conventional steering system. The lift truck’s design allows for ample leg room and can be adjusted in two planes – height and proximity – for optimum comfort and productivity.

SOLO-/MULTI-PILOT Controls

These options offer precise control and help improve productivity in your operation. A travel directional switch and horn are conveniently integrated into the fingertip module.

Full Suspension Seat

The three-way adjustable full-suspension seat and fully-floating cab design help reduce shock and vibration.

More Efficiency, Less Maintenance

The Lithium-ion battery package provides the highest performing battery solution.

  • High performance batteries that are synchronized with the lift truck and charger for optimal energy efficiency



  • No maintenance requirements and a longer service life mean each truck offers more daily use, increased throughput and reliable 24/7 performance



  • No more battery change outs, watering and degassing areas



  • Maximize truck productivity through opportunity charging that can be interrupted anytime



  • 5-year warranty included
Model Basic Capacity (lbs) Maximum Fork Height2 Voltage (or Fuel Type) Length to Fork Face Chassis Width (in) Chassis Height (in)1 Gross Weight (lbs)1
2ET2500
2,510
255
36/48
69.8
41.7
80.4
5,935/5,947
2ETC3000
3,100
216
36/48
74.3
41.7
80.4
6,523/6,520
2ET3000
3,100
255
36/48
78.5
41.7
80.4
6,654/6,627
2ETC3500
3,490
255
36/48
74.3
44.1
80.4
7,143/7,084
2ET3500
3,490
255
36/48
78.5
44.1
80.4
7,035/6,957
2ET4000
3,880
255
36/48
78.5
44.1
80.4
7,421/7,343

1 Where applicable, does not reflect optional mast collapsed height or additional weight.
2 Various lift heights available to match your exact needs. Where applicable, value shown is maximum fork height available as an optional mast.

Product Brochure - English

2ET2500-2ET4000 Three-Wheel Electric Lift Trucks

Product Brochure - Spanish

2ET2500-2ET4000 Three-Wheel Electric Lift Trucks
