Home » Mitsubishi Forklifts » FG15N – FG35N
The FG15N-FG35N / FD20N-FD35N LP/gas and diesel forklift series delivers superior lift and travel speeds, powerful acceleration and the ability to move more product. Lease a new 5,000 lb. capacity forklift for as low as $288/month.
Take advantage of historically low rates available on the entire lineup of small IC pneumatic tire Mitsubishi forklift trucks.
Equipped with an efficient GK21 / GK25 engine, these forklifts offer the power you need. A drive-by-wire throttle control allows for enhanced efficiency, reduced emissions and responsive acceleration, while the exhaust system provides a three-way catalyst that lowers the amount of emissions released into the environment.
The new 4EG 3.3L diesel engine is built with cutting edge emissions technologies to meet the Environmental Protection Agency’s (EPA) Tier 4 final requirements, while still maintaining the high levels of productivity that your business demands.
The transmission’s torque converter smoothly transfers the power from the forklift’s engine and multiplies the torque sent to the transmission – increasing power on demand.
Reduce the risk of major damage to your engine with the Engine Protection System. This system will continuously monitor certain areas of your engine and limit certain areas of operation if maintenance issues are not addressed.
Forklift trucks need to be durable, so our steel frames are built strong to help protect your lift truck during operation.
The rear-hinged engine hood gives you easy access to major components – without tools – so you can get your forklifts up and running quickly.
Spend less time and money on preventative maintenance with Mitsubishi’s extended service intervals.
Help ensure your operators are in the proper operating position with Mitsubishi’s Integrated Presence System (IPS). This standard feature will lock-out powered travel and hydraulic functions of the forklift when the operator isn’t in the proper operating position.
The bright orange anti-cinch seat belt makes it easier to identify when operators are not wearing their seat belts.
Mitsubishi forklift’s front LED work lights have a long life and will help save on maintenance costs vs. traditional halogen and incandescent lights. They are also covered in your standard warranty.
An extra long grip bar, a low height anti-slip step and steel hip restraint provide three solid points of contact when entering and exiting the forklift.
Noise and vibration can take a toll on your operators. Mitsubishi’s forklifts offer standard features to keep your operators less fatigued, including a fully-insulated engine hood, rubber mounted components, fully-enclosed wheel wells and helical transmission gears.
Our hydrostatic steering system makes steering the forklift easier for your operators and can also provide the added benefit of reducing your maintenance costs. No special tooling is required to pre-load the bearings, and the kingpin does not require greasing.
Low-effort levers, precise operation and an infinitely adjustable armrest provide comfortable support with ease of use for operators throughout the workday.
| Model | Basic Capacity (lbs) | Maximum Fork Height2 | Length to Fork Face | Chassis Width (in) | Chassis Height (in)1 | Gross Weight (lbs)1 |
|---|---|---|---|---|---|---|
|
FG15N |
3,000 |
131.0 |
89.0 |
41.9 |
82.7 |
5,650 |
|
FG18N |
3,500 |
131.0 |
90.4 |
41.9 |
82.7 |
6,070 |
|
FG20CN |
4,000 |
131.0 |
92.5 |
41.9 |
82.7 |
6,750 |
|
FG20N |
4,000 |
131.5 |
98.0 |
45.3 |
82.9 |
7,370 |
|
FD20N |
4,000 |
131.5 |
98.0 |
45.3 |
82.9 |
7,610 |
|
FG25N |
5,000 |
131.5 |
100 |
45.3 |
82.9 |
7,990 |
|
FD25N |
5,000 |
131.5 |
100 |
45.3 |
82.9 |
8,210 |
|
FG28N |
5,500 |
130.5 |
104 |
50.2 |
83.7 |
9,090 |
|
FD28N |
5,500 |
130.5 |
104 |
50.2 |
83.7 |
9,330 |
|
FG30N |
6,000 |
130.5 |
107 |
50.2 |
83.7 |
9,400 |
|
FD30N |
6,000 |
130.5 |
107 |
50.2 |
83.7 |
9,640 |
|
FG33N |
6,500 |
131.5 |
108 |
50.2 |
83.7 |
10,150 |
|
FD33N |
6,500 |
131.5 |
108 |
50.2 |
83.7 |
10,390 |
|
FG35N |
7,000 |
131.5 |
110 |
50.8 |
84.3 |
10,340 |
|
FD35N |
7,000 |
131.5 |
110 |
50.8 |
84.3 |
10,590 |
¹ Where applicable, does not reflect optional mast collapsed height or additional weight.
² Various lift heights available to match your exact needs. Where applicable, value shown is maximum fork height available as an optional mast.
Talk to a Mitsubishi specialist who can help find the best solution for your needs and budget.
