Home » Mitsubishi Forklifts » FBC20Q-FBC40Q
The FBC20Q-FBC40Q cushion tire forklift series has a comfortable operator compartment with advanced dual drive motors and intelligent controls to achieve your cost of ownership goals.
Work longer with up to two shifts on one battery charge without sacrificing performance.
Optimize your performance and efficiency by simply selecting one of the pre-set operating modes. Profits are maximized by achieving the right balance between output and economy.
This integrated, computer-based feedback system uses both audible and visual indicators to alert the operator to potentially hazardous situations, while increasing operator awareness.
These trucks sense operating conditions and automatically respond with adjustments to motor outputs – including travel speed, lift/lower acceleration, and mast sway – to help encourage safe working practices.
Thanks to the design of the FBC20Q-FBC40Q models your operators can deliver the productivity you need to get the job done.
Advanced AC motors
Optimized regenerative braking system
The two-stage hydraulic system determines the optimum motor speed, resulting in reduced energy consumption and longer run times.
From the beginning of the shift to the end, this forklift was designed for optimal comfort. Operators can easily adjust the seat to their preferences – from forward and backward adjustments, to added lumbar support and suspension. The low-profile steering wheel also provides extra space and comfort.
Located next to the seat, the hydraulic levers allow the operators arm to rest in a natural, relaxed position while working. Optional fingertip controls are also available for added ergonomics and productivity.
This seat helps reduce shock and vibration while optimizing comfort and productivity via 4-way adjustments, including lumbar support, weight suspension and forward/backward adjustments
Easily removable side, top, floor and rear access panels, make accessing the motors and major components simple, saving you time and money.
These brighter lights provide excellent illumination while loading and unloading trailers or in dark areas. New narrow design offers better protection and easy access to trailer containers.
The all welded box frame and battery edge cover design helps to extend the life of your investment.
Built with advanced AC electric power and intelligent controls, the FBC20Q-FBC40Q series redefines maneuverability. This isn’t just a lift truck—it’s a performance tool designed to help your operators work faster, smarter, and more efficiently.
| Model | Capacity (lb) | Height2 (in) | Voltage | Length (in) | Width (in) | Height (in)1 | Weight (lb)1 |
|---|---|---|---|---|---|---|---|
|
FBC23N |
4,500 |
131.5 |
36/48 |
82.0 |
41.5 |
88 |
8,750 |
|
FBC25EN |
5,000 |
131.5 |
36/48 |
85.9 |
41.5 |
88 |
9,300 |
|
FBC25LN |
5,500 |
131.5 |
36/48 |
85.9 |
43.5 |
88 |
9,650 |
|
FBC25N |
5,000 |
131.5 |
36/48 |
82.0 |
41.5 |
88 |
9,100 |
|
FBC30N |
6,000 |
130.3 |
36/48 |
88.0 |
43.5 |
88 |
10,600 |
¹ Where applicable, does not reflect optional mast collapsed height or additional weight.
² Various lift heights available to match your exact needs. Where applicable, value shown is maximum fork height available as an optional mast.
