Bendi Rear Wheel Drive – Narrow Aisle Multipurpose High Lift Articulating Electric Forklift

The Bendi model B40AC-HL works in aisles as narrow as 78″* (1.98M), has a basic starting capacity of 4,400 lbs. (1996 kg) at 24″ (600mm) load center and has lift heights available to 41′ (12.50M).

The Bendi B40AC-HL is a 4-wheel articulating forklift with dual independently driven rear-drive tires and soft-poly front load tires. The B40AC-HL can work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The B40AC-HL does all of the jobs of a reach and counterbalanced truck but in much narrower aisles.

  • Features
  • Specifications
  • Downloads

Exceptional Performance and Maneuverability

Equipped with the Landoll DuraSteerTM front wheel hydraulic steering, the B40AC-HL provides exceptional control and makes load placement and retrieval superior to the competition.

3-Stage Mast

The new mast has a rigid mounting and as standard a tilting and side shifting carriage. The new design offers increased mast rigidity, capacity and improved visibility. Dual free lift cylinders and optimized hose and chain routings have improved visibility thru the mast. Lowered heights have been reduced and a new mounting position on the 42” (1067 mm) wide front axle reduces the distance from the face of the forks to the back of the axle thereby improving aisle performance. Mountings for cameras have been integrated into the inner mast and an optional integral side shifting fork positioner combination is also available.

*Based on 48” (1200mm) long x 40” (1000mm) wide load.

  • 4,400 lb. (1,996kg) and 5,000 lb. (2,268kg) Capacity at 24″ (600mm) Load Center
  • Four-Wheel Design, Dual Rear Wheel Drive
  • Adjustable Seat and Steering Wheel
  • Integral 11.2″ (285mm) Stroke Sideshifter and 36″ (914mm) High Load Backrest
  • DuraSteerTM Front Wheel Hydraulic Steering Provides Smooth, Reliable, Long-Lasting Steering Control
  • Independently Controlled Rear Wheels Allow Independent Speed Control of Each Drive Tire Based on Steering Angle
  • Creep Speed Mode Adds Enhanced Control when Handling Loads at High Elevations or While Training Operators
  • High Visibility Mast Allows Optimum Safety and Control
  • AC Traction and Hydraulic Motors Ensure Minimal Maintenance and High Efficiency
  • High-Efficiency Curtis AC Controllers Provide Trouble Free Operation
  • Interactive LCD Status Monitor (BDI with Lift Interrupt, Hour Meter with Service Monitor, Diagnostic Code Display, Input Device Calibration)
  • 48 Volt Electrical System
  • Optional Cold Storage Conditioned to -22°F (-30°C)

Standard Specifications

  • 4,400 lb. (1,996kg) and 5,000 lb. (2,268kg) Capacity at 24” (600mm) Load Center
  • Lift Heights to 492” (12.5M)
  • Four-Wheel Design, Dual Rear Wheel Drive
  • High Visibility 3-Stage Mast
  • Integral 11.2” (285mm) Stroke Side Shifter and 36” (914mm) High Load Backrest
  • Adjustable Seat and Steering Wheel
  • Dual Curtis AC Traction Motor Controllers
  • Curtis AC Hydraulic Motor Controller
  • Battery Discharge Indicator with Lift Interrupt
  • Electronic Regenerative and Hydraulic Disc Braking
  • “Floating” Articulated Front Axle
  • 180º Front-End DuraSteer™ Articulation / Steering Assembly with 5-Year Warranty
  • Safety Seat Switch, Seat Belt and Rear View Mirror
  • Curtis Engage Dash Display
  • Hand Actuated Parking Brake
  • Non Tilting Rigid Mounted Mast
  • Carriage Tilt 0º Forward / 3º Backward
  • Smooth Rubber Drive Tires
  • Soft Polyurethane Load Wheel Tires
  • 40” (1,000mm) Tapered Tip Forks – Rear Tow Hitch Pin
  • Three Section Hydraulic Control Valve
  • Meets ANSI B56.1

Optional Equipment

  • Non-Standard Fork Lengths
  • Dual Overhead Guard-Mounted LED Headlights
  • Dual Rear Safety LED Light Bars
  • Safety Flashing LED Light
  • Backup Alarm – Beeping Tone (“Smart” dB Adjusting)
  • Blue Pedestrian Warning Spotlights
  • Fire Extinguisher – OHG Post Mounted
  • Roller / Slide-Out Battery Tray
  • Lazer Fork Height Indicator
  • Hydraulic Integral Fork Positioner
  • Hydraulic Fork Extensions
  • Camera with Monitor in Operator’s Compartment
  • Cold Storage Conditioned to -22°F (-30°C)

TECHNICAL DATA

Model B40AC-HL
Capacity
at 24" (600mm) Load Center
lbs/kg
4,400 / 1,996
Weight
with Battery
lbs/kg
14,270 / 6,486
Travel Speed
Loaded
mph/kph
6.5 / 10.5
Travel Speed
Unloaded
mph/kph
7 / 11.3
Lift Speed
Loaded
fpm/mpm
90 / 27.4
Lift Speed
Unloaded
fpm/mpm
110 / 33.4
Lowering Speed
Loaded
fpm/mpm
100 / 30.5
Lowering Speed
Unloaded
fpm/mpm
90 / 27.4
Mast Tilt
Fwd / Back - Up to 293" (7.44M)
deg
0 / 3
Lost Load Center
E
in/mm
12 / 305
Wheelbase
F
in/mm
734 / 1,864
Rear Overhang
G
in/mm
28.6 / 726
Overall Length Fork to Face
H
Mast Vertical
in/mm
114 / 2,896
Underclearance
I
in/mm
3 / 76
Cab Floor Height
J
in/mm
31.3 / 795
Seat Height
K
in/mm
52 / 1.321
Overhead Guard Weight
L
in/mm
89 / 2,261
Chassis Width
M
in/mm
50 / 1,270
Battery Compartment Height
N
in/mm
19.24 / 489
Fork Length
O
in/mm
40 / 1016
Front Articulation
P
deg
180
Front Axle Width
in/mm
42 / 1,067
Gradeability
Unloaded
%
15
Gradeability
with 48"L x 40"W (1200mm x 1000mm) Load
%
15
Hydraulic Motor Rating
Continuous Duty Rating
type/kW
AC / 12
Drive Motor Rating
Continuous Duty Rating
type/kW
AC / 2 x 5.6 11.2 Total
Traction Control Type
Curtis
AC
Hydraulic Control Type
Curtis
AC
Wheel Sizes
Front (1 Each) Poly - Dia. x Face
in/mm
14x5 / 356x127
Wheel Sizes
Rear (2 Each) Rubber - Dia. x Face
in/mm
18x7 / 457x178

MAST DIMENSIONS

A - LIFT HEIGHT (Inches) A - LIFT HEIGHT (Meters) B - LOWERED HEIGHT (Inches) B - LOWERED HEIGHT (Meters) C - FREE LIFT (Inches) C - FREE LIFT (Meters) D - OVERALL HEIGHT (Inches) D - OVERALL HEIGHT (Meters)
312
7.92
140
3.56
104
2.64
348
8.83
327
8.31
145
3.68
109
2.77
363
9.22
360
9.14
156
3.96
120
3.05
396
10.05
375
9.53
161
4.09
125
3.18
411
10.44
417
10.59
175
4.45
139
3.53
453
11.50
435
11.05
181
4.60
145
3.68
471
11.96
471
11.96
193
4.90
157
3.99
507
12.87
492
12.50
200
5.08
164
4.17
528
13.41

AISLE DIMENSIONS

LOAD DEPTH X WIDTH MINIMUM CLEAR AISLE
40" X 48" (1,000 X 1,200mm)
78" (1,930mm)
48" X 40" (1,200 X 1,000mm)
78" (1,930mm)
Transfer or End Aisle
114" (2,896mm)

RECOMMENDED BATTERY

LOAD DEPTH X WIDTH
Nominal Size: 44.75" x 32.25" x 22.63" (114 x 82 x 58cm)
Truck Compartment Size: 44.875" x 32.5" x 23" (114x83x59cm)
Battery Weight Min: 3,500 lbs. (1,590kg) Max: 4,000 lbs. (1,818kg)
Leads are at Position A, 12" (30.5cm) Long, with SB 350 Amp Blue Connector
