3,000 - 4,500 lb. Capacity 36 Volt Electric Reach Truck Forklift
The ETR pantograph reach truck forklift series runs two shifts on one battery charge, guaranteed, allowing your operators to maximize their workday.
Productivity
Quick acceleration, fast travel speeds, and one of the fastest lifting speeds (165 feet per minute) leads to faster placement and pick-up of loads for greater throughput and efficiency.
3 customizable performance modes for virtually any application and operator experience level, which equates to greater productivity.
Lift Height Indicator with Shelf Pre-selector –significantly increases productivity.
Energy Efficiency
We guarantee your lift truck will run for 16 hours with no interim charging, no battery changing and no additional charging equipment required – saving valuable operator time and reducing your overall costs.
Advanced Regenerative Braking
This technology recovers energy when reversing or when the control handle is returned to a neutral position, leading to fewer battery changes and ultimately helping to increase throughput and productivity.
AC Technology – 6th Generation
Next Generation AC technology provides for less energy consumption, higher torques, faster lift and travel speeds and longer run times.
AC Electric Power Steering
Steer with control – Positioning the reach truck in an aisle is simplified with the ETR’s electronic power steering. This drive-by-wire system is extremely smooth and quiet and requires minimal effort to operate.
Industry Exclusive Support
5-Year Powertrain Warranty
Industry’s only standard 5-year / 10,000 powertrain warranty – including parts and labor on all powertrain components.
Low Maintenance
1,000 hours service interval means more uptime with less time, effort and money spent on maintenance.
Operator Assistance
curveCONTROL
Automatically reduces travel speed when cornering and helps keep the truck and load stable and secure.
Operator Presence
Two-pedal Operator Presence system activates alerts or stops specific functions on the truck.
Capacity Retention
Superior Capacity retention at height – base legs integrated into the chassis and not the mast as on many competitor trucks
Ergonomics
Comfort
Operator friendly design with comfortable cushions position at operator contact points – knee, back, hip and armrest padding.
Efficiency
Exclusive Jungheinrich-designed intuitive multi-function control handle provides outstanding job accuracy and efficiency.
Precision
All electric power steering allows for precise and effortless control.
What Customers Are Saying
“The (Jungheinrich) equipment that we have is top of the line and really stands out compared to what we used to have.” – Brent Cable, Industrial Engineer
Lithium-Ion Package Advantages
- Fast charging with no need for battery exchanges
- Maintenance-free with no odors from gases or acidification
- Longer service life compared to lead-acid batteries
- Charging can be interrupted at anytime
- 5-year battery warranty included
| Model | Basic Capacity (lbs) | Maximum Fork Height2 | Voltage (or Fuel Type) | Length to Fork Face | Chassis Width (in) | Chassis Height (in)1 | Gross Weight (lbs)1 |
|---|---|---|---|---|---|---|---|
|
ETR214 |
3,000 |
242 |
36 |
52 |
41.5 |
95 |
6,850 |
|
ERT216 |
3,500 |
242 |
36 |
52 |
41.5 |
95 |
6,850 |
|
ETR318 |
4,000 |
242 |
36 |
54 |
41.5 |
92.5 |
7,050 |
|
ETR320 |
4,500 |
242 |
36 |
55 |
41.5 |
92.5 |
7,050 |
|
ETR316D |
3,500 |
242 |
36 |
54 |
41.5 |
92.5 |
7,400 |
1 Where applicable, does not reflect optional mast collapsed height or additional weight.
2 Various lift heights available to match your exact needs. Where applicable, value shown is maximum fork height available as an optional mast.
